How to Set Up a High Peak Canopy Kit
Whether you're hosting a backyard wedding, setting up at a festival, or adding a permanent covered space to your property, a high-peak canopy kit from Tarps.com is one of the most versatile structures you can own. Best of all, the entire setup requires zero tools — just your hands and a few minutes of your time.
Here's a step-by-step guide to get you up and covered.
What You'll Need
Before you get started, lay out all of your parts and do a quick inventory to make sure everything is accounted for. Parts may vary slightly between kit sizes, but the assembly process is the same across all of our high-peak canopy kits.
Step 1: Measure Your Space
Start by measuring the area where you plan to set up. For this guide, we're working with a 10' x 20' canopy. Make sure you have adequate clearance on all sides before you begin building.
Step 2: Build the Spine
The spine is the topmost peak of the canopy frame. To assemble it, you'll need:
- Two 10' poles
- Two three-way high-peak fittings
- One four-way high-peak fitting
The three-way fittings go on the ends, and the four-way fitting goes in the middle. One thing that makes high-peak canopies especially straightforward to work with: the top and sides are all cut to the same angle, so you don't have to guess which poles go where.
Step 3: Add the Rafters
Next, attach the rafters — the angled poles that extend down from the spine. Always double-check that each pole is slid all the way into its fitting. A pole that isn't fully seated will cause problems when it comes time to attach the tarp.
Step 4: Assemble the Lower Roof Frame
With the rafters in place, you can finish out the roof frame. This section uses:
- Four 10' poles
- Two three-way fittings (one for each end of the canopy)
- Two four-way fittings (for the center)
The same rule applies here — three-ways on the ends, four-ways in the middle.
Step 5: Attach the Tarp
Take out your tarp and note that it's intentionally larger than the frame. That extra material is designed to drape over the sides and cover the grommet holes.
Quick tip for square frames: If you're working with a 10' x 10' or 20' x 20' canopy, the sides of the tarp with the pocket hem and rope running through them are your gable ends. Orient the tarp accordingly before you start attaching.
Start by orienting the tarp so the hemmed rope sides are on the gable ends. Then attach the tarp by connecting opposite corners first. Use two ball bungees in each corner grommet — this stabilizes the tarp and keeps it from slipping in either direction.
Once the corners are secure, attach the tarp at the peak, then work your way around and clip in the remaining ball bungees.
Step 6: Attach the Legs
Now it's time to stand your canopy up. Attach the legs starting from the middle and working your way out to the ends. Once all the legs are on, don't forget to cinch down the rope at each end of the canopy.
Step 7: Anchor It Down
Once your canopy is fully assembled, secure it against wind and weather. The most common anchoring options are:
- Earth anchors — ideal for grass or soft ground
- Tent stakes — a lightweight, easy option for temporary setups
- Buckets filled with concrete or sand — great for hard surfaces or permanent installations
The larger your canopy, the more anchoring weight you'll need. Plan accordingly, especially if you're in an area that sees wind.
That's It — You're Set!
High-peak canopy kits are built to be straightforward, and with a little practice, you'll have the setup down to a science. Whether you're using yours as a permanent backyard structure or a quick-deploy shelter for your next event, we're confident it'll serve you well for years to come.
Have questions about sizing, anchoring, or finding the right tarp for your kit? Our team is here to help. Visit us at Tarps.com, and we'll get you sorted.
